Bluetooth
5.4
-
LAN
1 x Realtek 5Gb Ethernet;ASUS LANGuard
-
Manufacturer
ASUS
-
OS
Windows 11 (22H2 & later)
-
Vendor_url
https://rog.asus.com/motherboards/rog-crosshair/rog-crosshair-x870e-apex/
-
Graphics
2 x USB4® (40Gbps) ports support USB Type-C® display outputs*;Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.;VGA resolution support depends on processors' or graphic cards' resolution.;*Supports max. 4K@60Hz as
-
Audio
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*;- Impedance sense for front and rear headphone outputs;- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking;- High quality 120 dB SNR stereo playback output and 1
-
Memory type
2 x DIMM slots, max. 128GB, DDR5 ;Supports up to;8200+MT/s(OC) with Ryzen™ 9000 Series Processors,;9600+MT/s(OC) with Ryzen™ 8000 Series Processors;8000+MT/s(OC) with Ryzen™ 7000 Series Processors,;ECC and Non-ECC, Un-buffered Memory*;Dual channel memory
-
Warranty
36 Months
-
Expansion Slots
AMD Ryzen™ 9000 & 7000 Series Desktop Processors*;2 x PCIe 5.0 x16 slots with Q-Release Slim (supports x16 or x8/x8** or x8/x4/x4 modes***);** When you use both PCIEX16_1 and PCIEX16_2, PCIEX16_1 and PCIEX16_2 will run x8. ;***When M.2_3 are enabled, PCIE
-
Storage
Supports 5 x M.2 slots and 4 x SATA 6Gb/s ports*;AMD Ryzen™ 9000 & 7000 Series Desktop Processors***;M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode);M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode);M.2_3 slot (Key M)
-
Chipset
AMD X870E
-
Дънна платка - сокет
AM5
-
Дънна платка - чипсет
AMD X870E
-
Дънна платка - поддържан тип памет
DDR5
-
Дънна платка - брой слотове за памет
2 бр
-
Дънна платка - честота на паметта
7000 MHz
8000 MHz
8200 MHz
9000 MHz
9600 MHz
-
Дънна платка - интерфейси
M.2 (NVMe) конектор
M.2 (SATA) конектор
SATA 3.0
-
Дънна платка - портове
USB 3.2
USB 4.0
-
Дънна платка - форм фактор
ATX
-
USB
Rear USB (Total 10 ports);2 x USB4® (40Gbps) ports (2 x USB Type-C®);6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C®) 2 x USB 5Gbps ports (2 x Type-A);Front USB (Total 10 ports);1 x USB 20Gbps (supports USB Type-C® with up to 60W PD/QC4+)*;1 x USB 20Gb
-
Form Factor
ATX Form Factor;30.5 cm x 24.4 cm
-
Rear panel I/O
2 x USB4® (40Gbps) ports (2 x USB Type-C®);6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C®) ;2 x USB 5Gbps ports (2 x Type-A)1 x Wi-Fi module;1 x Realtek 5Gb Ethernet port;1 x PS/2 keyboard/mouse combo port ;2 x Gold-plated audio jacks1 x Optical S/PDI
-
BIOS
2 x 256 Mb Flash ROM, UEFI AMI BIOS
-
Connectors
Fan and Cooling Related ;1 x 4-pin CPU Fan header;1 x 4-pin CPU OPT Fan header1 x 4-pin AIO Pump header;2 x 4-pin Chassis Fan headers;2 x 4-pin Full Speed Fan headers;1 x W_PUMP+ header;1 x Extra Flow Fan header;Power Related;1 x 24-pin Main Power connect
-
CPU's supported
AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors
-
Wireless
Wi-Fi 7 (Qualcomm QCNCM865 or MediaTek MT7927);2x2 Wi-Fi 7 (802.11be) ;Supports 2.4/5/6GHz frequency band;Supports Wi-Fi 7 320MHz bandwidth;Bluetooth® v5.4
