Bluetooth
5.4
-
LAN
1 x Intel® 2.5Gb Ethernet;1 x Marvell® AQtion 10Gb Ethernet;ASUS LANGuard
-
Manufacturer
ASUS
-
OS
Windows 11 (22H2 & later)
-
Vendor_url
https://rog.asus.com/motherboards/rog-maximus/rog-maximus-z890-extreme/
-
Graphics
1 x HDMITM port;2 x Intel® Thunderbolt™ 5 ports (USB Type-C®) support DisplayPort and Thunderbolt™ video outputs
-
Audio
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082;- Impedance sense for front and rear headphone outputs;- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking;- High quality 120 dB SNR stereo playback output and 11
-
Memory type
4 x DIMM slots, max. 256GB, DDR5;Support up to 9200+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM);Dual Channel Memory Architecture;Supports Intel® Extreme Memory Profile (XMP) memory module;ASUS Enhanced Memory Profile III (AEMP III);S
-
Warranty
36 Months
-
Expansion Slots
Intel® Core™ Ultra Processors(Series 2);2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 or x8/x4/x4 modes);Intel® Z890 Chipset;1 x PCIe 4.0x4 slot
-
Storage
Total supports up to 6 x M.2 slots and 4 x SATA 6Gb/s ports;Support Intel® Core™ Ultra Processors(Series 2);M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode);M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode);M.2_3
-
Chipset
Intel® Z890 Chipset
-
Дънна платка - сокет
LGA1851
-
Дънна платка - чипсет
INTEL Z890
-
Дънна платка - поддържан тип памет
DDR5
-
Дънна платка - брой слотове за памет
4 бр
-
Дънна платка - честота на паметта
9200 MHz
-
Дънна платка - интерфейси
M.2 (NVMe) конектор
M.2 (SATA) конектор
SATA 3.0
-
Дънна платка - портове
USB 3.2
-
Дънна платка - форм фактор
Extended-ATX
-
USB
Rear USB (Total 10 ports);2 x Thunderbolt™ 5 ports (2 x USB Type-C®);1 x USB 20Gbps port (1 x USB Type-C®);7 x USB 10Gbps ports (5 x Type-A + 2 x USB Type-C®);Front USB (Total 10 ports);1 x USB 20Gbps connector (supports USB Type-C® with up to 60W PD/QC4+
-
Form Factor
E-ATX Form Factor;30.5 cm x 27.7 cm
-
Rear panel I/O
2 x Thunderbolt™ 5 USB Type-C® ports;1 x USB 20Gbps port (1 x USB Type-C®);7 x USB 10Gbps ports (5 x Type-A + 2 x USB Type-C®);1 x HDMITM port;1 x Wi-Fi Module;1 x Intel® 2.5Gb Ethernet port;1 x Marvell® AQtion 10Gb Ethernet port2 x LED-illuminated audio
-
BIOS
2 x 256 Mb Flash ROM, UEFI AMI BIOS
-
Connectors
Fan and Cooling related;1 x 4-pin CPU Fan header;1 x 4-pin CPU OPT Fan header;2 x 4-pin Chassis Fan headers;2 x 4-pin Radiator Fan headers;2 x W_PUMP+ headers;1 x WB_SENSOR header;Power related ;1 x 24-pin Main Power connector2 x 8-pin +12V CPU Power conn
-
CPU's supported
Support Intel® Core™ Ultra Processors (Series 2) , LGA1851;Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0
-
Wireless
Intel® Wi-Fi 7;2x2 Wi-Fi 7 (802.11be);Supports 2.4/5/6GHz frequency band;Support Wi-Fi 7 320MHz bandwidth, up to 5.8Gbps transfer rate;Bluetooth® v5.4
